Hydraulic exercise equipment: History and Key Facts

Hydraulic exercise equipment is a form of strength training equipment based on fluid dynamics to provide motion resistance by use of hydraulic cylinders. They can be used in a number of strength training programs, and are most often found in circuit training gyms.

Hydraulic circuit training machines were first developed for The Henley Corporation in the 1970s, and are now becoming an increasingly popular form of exercise.

The fundamental principles behind these designs are based on fluid dynamics: Force that is applied at one point is transmitted to another point using an incompressible fluid known as hydraulic oil.

For circuit training applications, each piece of equipment is specifically designed for a given exercise. The effort is applied through the range of motion of the exercise acts on a lever against a piston which moves linearly within a hydraulic cylinder. The cylinder is filled with hydraulic oil which is displaced by the motion of the piston, and is allowed to flow to the opposite side of the piston through an adjustable orifice.
